DIN 标准导轨接线盒
添加到购物车内 至少组件 (相对单件)
1 个下盒，型式 I
1 款视面 (上盒或铝材质前面板)
1 个电池盒及盒盖
或
1 个下盒，型式 II
1 款视面 ( ABS 塑料视面板或玻璃板).
1 个电池盒及盒盖.
系统组件使产品完整
B4042407
Cover S
Assembly unit: suitable for bottom part vers. I. For protecting the electronics. Integrated screw pillars for PCB fixing. Recessed operating area for protecting the membrane keyboard. Fixing from the rear.
Supply 1 cover, assembly kit
关闭B4042407
Cover S产品已添加到关注清单中
off-white RAL 9002
190x135x14mm
B4042707
Bottom part S flat, version I
Assembly unit: unique variety of applications -mobile / desk-top and wall mounted. With screw pillars for PCB fixing. End piece for bottom part required - depending on the application - battery compartment and lid / bottom panel with handle recess / bottom panel with snap-in strips, base (desk-top), base (station for mobile cases) or base (desk-top/wall) can be assembled - see separate articles.
Version Suitable for mounting cover or aluminium front panel (sep. article)
Supply 1 bottom part flat
关闭B4042707
Bottom part S flat, version I产品已添加到关注清单中
off-white RAL 9002
190x135x24.5mm
IP 54 opt.
B4042717
Bottom part S flat, version II
Assembly unit: unique variety of applications -mobile / desk-top and wall mounted. With screw pillars for PCB fixing. End piece for bottom part required - depending on the application - battery compartment and lid / bottom panel with handle recess / bottom panel with snap-in strips, base (desk-top), base (station for mobile cases) or base (desk-top/wall) can be assembled - see separate articles.
Version Suitable for mounting ABS front panel or glass panel (sep. article)
Supply 1 bottom part flat
关闭B4042717
Bottom part S flat, version II产品已添加到关注清单中
off-white RAL 9002
190x135x24.5mm
IP 54 opt.
B4042757
Bottom part S high, version I
Assembly unit: unique variety of applications -mobile / desk-top and wall mounted. With screw pillars for PCB fixing. End piece for bottom part required - depending on the application - battery compartment and lid / bottom panel with handle recess / bottom panel with snap-in strips, base (desk-top), base (station for mobile cases) or base (desk-top/wall) can be assembled - see separate articles.
Version Suitable for mounting cover or aluminium front panel (sep. article)
Supply 1 bottom part high
关闭B4042757
Bottom part S high, version I产品已添加到关注清单中
off-white RAL 9002
190x135x34.5mm
IP 54 opt.
B4042767
Bottom part S high, version II
Assembly unit: unique variety of applications -mobile / desk-top and wall mounted. With screw pillars for PCB fixing. End piece for bottom part required - depending on the application - battery compartment and lid / bottom panel with handle recess / bottom panel with snap-in strips, base (desk-top), base (station for mobile cases) or base (desk-top/wall) can be assembled - see separate articles.
Version Suitable for mounting ABS front panel or glass panel (sep. article)
Supply 1 bottom part high
关闭B4042767
Bottom part S high, version II产品已添加到关注清单中
off-white RAL 9002
190x135x34.5mm
IP 54 opt.
B4142106
Front panel S
Assembly unit: suitable for bottom part vers. I. For mounting operating elements of all kinds.
Supply 1 front panel, assembly kit
关闭B4142106
Front panel S产品已添加到关注清单中
matt anodised
186.5x131.5x2mm
B4142107
Front panel S
Assembly unit: suitable for bottom part vers. II. For mounting operating elements of all kinds.
Supply 1 front panel, assembly kit
关闭B4142107
Front panel S产品已添加到关注清单中
off-white RAL 9002
190.6x135.6x14.5mm
B4142203
Glass panel S
Assembly unit: suitable for bottom part vers. II. Front design without printing. Various media and environmental parameters affect the adhesion of the adhesive foil. Please check before use if it is suitable for your application.
Version Safety glass with anti-reflex coating, high scratch-resistance, very easy to clean
Supply 1 glass panel incl. mounting frame and adhesive foil
关闭B4142203
Glass panel S产品已添加到关注清单中
clear
190.6x135.6x16.7mm
“保护等级” 附件
B4142005
Sealing S (bottom part - front design)
For a higher protection class. Suitable between bottom part and front design (cover / aluminium front panel / ABS front panel or glass panel).
Supply 1 sealing
关闭B4142005
Sealing S (bottom part - front design)产品已添加到关注清单中
B4142006
Sealing S (bottom part - base/bot. panel/bat. comp...)
For a higher protection class. Suitable between
- bottom part and base / bottom panel / battery compartment respectively
- base and base cover (station for charging station, case deposit mobile).
- bottom part and base / bottom panel / battery compartment respectively
- base and base cover (station for charging station, case deposit mobile).
Supply 1 sealing
关闭B4142006
Sealing S (bottom part - base/bot. panel/bat. comp...)产品已添加到关注清单中
附件
A9178007
Contacts, male
Application: 6-pole version for transfer of the charging current and the data exchange. See assembly instruction.
Supply 1 contact
关闭A9178007
Contacts, male产品已添加到关注清单中
A9178008
Contacts, female
Application: 6-pole version for transfer of the charging current and the data exchange. See assembly instruction.
Supply 1 contact
关闭A9178008
Contacts, female产品已添加到关注清单中
