A3131639 COM-KNOBS 31, without recess
Scroll

A3131639

COM-KNOBS 31, without recess

Suitable for rotary potentiometer with round shaft ends according to DIN 41591. Collet system for convenient knob assembly from the front. Borehole without chamfer.
Max. torque: assembly = 1.8 Nm, function = 1.6 Nm.

Supply

1 COM-KNOB (without recess)

Plano 2D en PDF
Vista en 3D en PDF
Añadir a la cesta de la compra Añadir a la cesta de la compra Añadir a la cesta de la compra
Producto añadido a su lista
Continuar o abrir la cesta de la compra
Crear ficha de datos PDF

Cree su ficha de datos en PDF para A3131639

Seleccione la información del producto para su ficha de datos.

Cerrar
  • Componentes adecuados
  • Modificaciones específicas del cliente

System components to complete

A3231003 Cover 31

A3231003

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231003

Cover 31
Producto añadido a su lista
PA 6
coral
A3231004 Cover 31

A3231004

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231004

Cover 31
Producto añadido a su lista
PA 6
beach
A3231005 Cover 31

A3231005

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231005

Cover 31
Producto añadido a su lista
PA 6
lagoon
A3231006 Cover 31

A3231006

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231006

Cover 31
Producto añadido a su lista
PA 6
sky
A3231007 Cover 31

A3231007

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231007

Cover 31
Producto añadido a su lista
PA 6
mineral
A3231009 Cover 31

A3231009

Cover 31 Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231009

Cover 31
Producto añadido a su lista
PA 6
nero
A3231011 Cover 31

A3231011

Cover 31 Cover with a matt chrome finish for a classy metallic look. Suitable for COM-KNOB 31. Cover simply to pin up.

Supply 1 cover

Cerrar

A3231011

Cover 31
Producto añadido a su lista
ABS (UL 94 HB)
matt chromed

Accessory "screws"

A6207009 Round nut M7 x 0.75

A6207009

Round nut M7 x 0.75

For fixing the potentiometers at front panels.

Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.

Supply 1 round nut

Cerrar

A6207009

Round nut M7 x 0.75
Producto añadido a su lista
A6210009 Round nut M10 x 0.75

A6210009

Round nut M10 x 0.75

For fixing the potentiometers at front panels.

Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.

Supply 1 round nut

Cerrar

A6210009

Round nut M10 x 0.75
Producto añadido a su lista
A6295009 Round nut 3/8"-32G

A6295009

Round nut 3/8"-32G For fixing the potentiometers at front panels.

Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.

Supply 1 round nut

Cerrar

A6295009

Round nut 3/8"-32G
Producto añadido a su lista
A6300000 Spanner

A6300000

Spanner For tightening the round nut. Suitable for round nuts M7 x 0.75, M10 x 0.75 and 3/8"-32G.

Supply 1 spanner

Cerrar

A6300000

Spanner
Producto añadido a su lista

Accessory

A4431010 Dial 31

A4431010

Dial 31 Dial simply to pin up for round knob 31 / COM-KNOB 31. Surface bright. Black symbol.

Supply 1 dial

Cerrar

A4431010

Dial 31
Producto añadido a su lista
PC (UL 94 HB)
transparent
A4431060 Dial 31

A4431060

Dial 31 Dial simply to pin up for round knob 31 / COM-KNOB 31. Surface bright. Black symbol.

Supply 1 dial

Cerrar

A4431060

Dial 31
Producto añadido a su lista
PC (UL 94 HB)
transparent
A7331000 Disk 31, without line

A7331000

Disk 31, without line Suitable for round knob 31 / COM-KNOB 31. Disk simply to pin up.

Supply 1 disk

Cerrar

A7331000

Disk 31, without line
Producto añadido a su lista
ABS (UL 94 HB)
black RAL 9005
A7331010 Disk 31, with line

A7331010

Disk 31, with line Suitable for round knob 31 / COM-KNOB 31. Disk simply to pin up. White marking.

Supply 1 disk

Cerrar

A7331010

Disk 31, with line
Producto añadido a su lista
ABS (UL 94 HB)
black RAL 9005

Customising options for A3131639

What else do you need to create your own personal product? We can supply our enclosures and tuning knobs fully modified to suit your electronic components and design requirements. Please advise for anything else we can do for you.

  • Datos técnicos
  • Planos / Documentos
  • Ejemplos de aplicación
  • Purchasing Data
Material
PA 6
Color
nero
Standards
RoHS compliant
REACH compliant
Diameter
31 mm
Height
16 mm
Bore hole ″
1/4″
Please take the dimensions from current parts. These are subject to material- and manufacturing-specific tolerances.

Drawings (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

3D-Models (Discrepancies depend on material-specific manufacturing tolerances, e.g. DIN EN 16742)

Weight/1 part
8 g
Customs tariff number
(OKW product)
84879090
Country of manufacture
Germany
